Corrosion Resistant Digital Metal Tube Rotameter High Accuracy
Product Details:
| Place of Origin: | Jiangsu, China |
| Brand Name: | INSTE |
| Model Number: | INSTE H250 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 200$-1000$ |
| Packaging Details: | wooden package |
| Delivery Time: | 3 work days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50 sets per day |
|
Detail Information |
|||
| Explosion Proof Grade: | Exia II CT5Ga, Exd II BT5Gb | Connection Form: | Stabndard:DIN2501 Standard Flange |
|---|---|---|---|
| Port: | Shenghai/ Shenzhen | Display Type: | Analog |
| Installation Height: | DN15-DN200:250mm; More Tahn DN80:350mm | Output: | NO |
| Scale Units: | L/min | Precision Class: | 1.5 |
| Applicable Medium: | Gas, Liquid | Exportation: | NO |
| Measurement Range: | 0-100 L/min | Connection: | Flange |
| Flow Direction: | Bottom To Top | Warranty: | 18 Months |
| Temperature Rating: | Max. 100°C | ||
| Highlight: | Corrosion Resistant Metal Tube Transmitter,Corrosion Resistant Metal Tube Float Flowmeter,High Accuracy Metal Tube Transmitter |
||
Product Description
Corrosion Resistant Metal Tube Transmitter High Accuracy For Different Applications
Measuring Principle:
The metal float flowmeter is an area flowmeter, which means that in the vertical measuring tube of the flowmeter, when the fluid flows upward through the tube, the float moves upward, and at a certain position, the lift and gravity of the float reach equilibrium. At this time, the flow clearance area between the float and the orifice plate (or cone tube) remains constant. The annular gap area is proportional to the rising height of the float, that is, a certain height of the float represents the size of the flow rate. When the float moves up and down, the position is transmitted to the external indicator in the form of magnetic coupling, so that the pointer of the indicator follows the movement of the float, and with the help of the cam plate, the pointer linearly indicates the size of the flow value. The electric remote transmission type is to accurately convert the flow value into a standard signal of 0-10mA or 4-20mA through the angle sensor and electric transmission circuit while indicating on site.
Features
1. Robust all-metal structure design.
2. Suitable for gas and liquid measurement in various industries.
3. Cone-shape measuring tube design,which has wide measuring range and good linearity.
4. Wetted parts material are optional: SS304, SS316L, FEP, Hastelloy C, Titanium.
5. Adopt advanced magnetic coupling system design, improve the accuracy and stability.
6. The upper row displays the instantaneous flow, the lower row displays the total flow.
7. For the digital LCD display type, the flow range of the instantaneous flow can be corrected onsite based on the different measuring medium.
8. It adopts advanced six level data backup technology,data of total flow can be saved automatically when power-off,(the total flow sending period id 0.3s).
| name | Corrosion Resistant Digital Metal Tube Rotameter High Accuracy |
| keyword | digital metal tube rotameter |
| Explosion Proof Grade | Exia II CT5Ga, Exd II BT5Gb |
| Connection Form | Stabndard:DIN2501 standard flange |
| Display Type | Analog |
